Medium Voltage Power Systems – 16 Hours

November 1, 2021 @ 8:00 am - October 31, 2024 @ 5:00 pm

$895.00
Medium Voltage Training

Medium Voltage Power Systems​
Live + On Demand

The backbone of many electric power systems is the medium voltage distribution system. What is medium voltage? It is typically voltages ranging from 2,400 to 34,500 Volts. This medium voltage training addresses voltage stress, surge arrestors, protection of equipment, insulation voltage classes, insulation coordination, equipment selection, operation and more.
16 Hours | 16 PDHs | 1.6 CEUs | $895.00

What You Will Receive with this Live Class:

  • 16 Hours of Live training by Jim Phillips, P.E.
  • In depth discussion of Medium Voltage Power Systems based on Jim’s 40+ years of experience.
  • Spiral bound notebook with 370+ printed slides.
  • Jim’s worksheets for current transformer saturation
  • Transformer differential protectoin calculation worksheets
  • On Demand version of this class that does not expire! $495.00 Value!
  • Interactive Q&A with Jim Phillips

Upon completion of this LIVE scheduled class, you will receive access to the 8 hour on-demand version for review and future reference.  The on-demand version does not expire!

Live Streaming Daily Schedule

Two – 2 Hour Sessions

One Hour Break Each Day

Eastern Time

11:00 AM – 1:00 PM
2:00 PM – 4:00 PM

Pacific Time

8:00 AM – 10:00 AM
11:00 AM – 1:00 PM

Registration Deadline

It is suggested to register several days before the class in order to receive the class material.

Bonus

Access to online version of this class is included

Discounts

25%

Register 4 or more

30%

Register 10 or more

Group/Corporate Rates

Available

Tickets

The numbers below include tickets for this event already in your cart. Clicking "Get Tickets" will allow you to edit any existing attendee information as well as change ticket quantities.
April 15 - 18, 2024 - Live Streaming
Live Streaming with interactive Q&A over 4 days | April 15 - 18, 2024 BONUS: FREE access will be provided to the Online version of this course.
$ 895.00
Unlimited
October 28 - 31, 2024 - Live Streaming
Live Streaming with interactive Q&A over 4 days | October 28 - 31, 2024 BONUS: FREE access will be provided to the Online version of this course.
$ 895.00
Unlimited

This 16 hour class by Jim Phillips, P.E. takes you through the fundamentals of medium voltage power systems including the components, equipment, design and operation problems as well as overcurrent protection, surge protection, insulation coordination and many other important aspects of medium voltage power systems.

Jim has developed this course based on his more than four decades of extensive experience with industrial, commercial and utility power systems and standards development.  He is not just another trainer reading a script.   Jim’s training is based on his insider’s view from being very active with many different standards committees which provides him with the unique perspective, literally from the inside.  Coupled with his broad electrical power background,  he loves sharing his experience and insider’s view with others.

One of the many topics that Jim discusses in this 16 hour class is overcurrent relays and relay settings including determining the current transformer ratio, CT saturation calculations, determining overcurrent relay settings and calculating transformer differential relay settings.  This class also includes many other topics such as surge protection, insulation coordination and more.

Medium Voltage
Medium Voltage Industrial Power Relay selective coordination
  • INTRODUCTION
    Medium Voltage Systems, Voltage Ranges, Special Considerations Failure Modes, Voltage Stress, Thermal Stress
  • MEDIUM VOLTAGE SAFETY TRAINING
  • Overview of Electrocution at Low vs. Medium Voltage, Arc Flash Issues, Qualified Person, Approach Boundaries
  • TYPES OF MEDIUM VOLTAGE SYSTEMS
    Utility and Industrial One lines, Reliability Requirements, Overhead and Underground Systems, Regulated Systems
  • MEDIUM VOLTAGE CABLE
    Copper vs. Aluminum Design, Voltage Ratings Insulation Ratings, 100%, 133%, 173% Insulation Levels, Shielding Requirements, Electric Fields, Medium Voltage Cable Termination, Orientation of Overhead Lines
  • MEDIUM VOLTAGE SUBSTATION TRANSFORMERS
    Core and Coil Design, Aluminum and Copper Windings, Transformer Characteristics, Tank Construction, Loss Evaluation, Loss Calculations, Efficiency Calculations, Regulation
  • SPOT NETWORKS
    Spot Network Design, Network Protectors, Network Protector Relay Operation, Directional Protection Requirements, Large Network Fault Currents
  • PARTIAL DISCHARGE
    Corona, Surface Tracking, Voltage Stress, Sensing Partial Discharge, Component Failure
  • GROUNDING MEDIUM VOLTAGE SYSTEMS
    Resistance Grounding, Solid Grounding, Ungrounded Delta Charging Current, Coefficient of Grounding Calculations, Effect of Ground Faults on Delta Voltage, Sizing Grounding Resistors, High Resistance Grounding vs. Low Resistance Grounding
  • OVERVIEW OF SYMMETRICAL COMPONENTS
    Positive, Negative and Zero Sequence Impedance, Per Unit Line-to-Ground Short Circuit Calculations
  • SURGE PROTECTION
    Lightning and Switching Surges, Classes of Surge Arresters, Insulation Basic Impulse Level BIL ,  Basic Impluse Switching Insulation Level (BSL) Front of Wave (FOW), MCOV Ratings – (Maximum Continuous Operating Voltage) TOV – (Maximum Temporary Over Voltage Capability), Protective Characteristics, Surge Arrester Selection, Energy Capability, Effect of Grounding on Arrester Selection, Insulation Coordination, Protective Ratio and Protective Margin Calculations.
  • CURRENT TRANSFORMER APPLICATIONS
    Ratings, Selection Process, Accuracy, Saturation, Excitation Curves, Burden, Calculation, Momentary Ratings, CT Saturation Calculations for Performance
  • MEDIUM VOLTAGE CIRCUIT BREAKERS
    Vacuum, Air, Oil, SF6 Designs, Symmetrical Interrupting Rating, K-Rated Voltage Factor, Close and Latch Capability
  • OVERCURRENT RELAYS
    Protective Relay Concepts, Selective Coordination Principles, ANSI Device Numbers i.e. 50, 51, 67, 32, 27, etc.  Amp Tap, Time Dial, Instantaneous Setting   Relay Setting Calculations, Digital Relays, Electromechanical Relays, Time Margins, Coordination Between Devices
  • RECLOSERS
    Application on Feeder Circuits, Recloser Settings, Continuous Current and Interrupting Ratings
  • MEDIUM VOLTAGE FUSES
    Medium Voltage Switches, Load Rating, Expulsion vs. Current Limiting Fuse Characteristics, E and R Rated Fuses, Fuse Cutouts, ANSI Time Current Points
  • MEDIUM VOLTAGE PROTECTION CONCEPTS
    Medium Voltage Protection, Relays, Circuit Breakers, R and E rated Fuses, Short Circuit vs. Overcurrent Protection
  • DISTRIBUTION FEEDER PROTECTION
    Protection with Fuses – 300%, Overcurrent Protection with Relays – 600%, Short Circuit Damage Characteristics, Relay “Reach” for End of Line Faults
  • ROTATING MACHINERY PROTECTION
    Protection Requirements, Generator Decrement Curves, Thermal Damage Curves, Reactive, Capability Curves, Differential Protection, Protection Example Calculations
  • MEDIUM VOLTAGE MOTOR CONTROLLERS
    Protection Requirements, Motor Management Relays, Circuit Breaker Protection, Relaying, Class R Rated Fuses
  • TRANSFORMER PROTECTION
    ANSI C57 Transformer Thru Fault Curves, Impact of Transformer Winding Configuration, Overview of Differential Protection, Inrush and Harmonic Restraint, Hands On Differential Relay Setting Calculation Problems and Calculation Worksheets.

Questions?

For questions, registration information or to discuss holding this class at your location as an on-site training program
