Per Unit and Symmetrical Components

Per Unit System and Symmetrical Components are at the heart of power system analysis. This training program by Jim Phillips takes you through the fundamentals of the Per Unit System and Symmetrical Components with many in-class calculation examples.
8 Hours | 8 PDHs | 0.8 CEUs | $495.00

What You Will Receive with this Live Class:

  • 8 Hours of Live training by Jim Phillips, P.E.
  • In depth discussion of Per Unit and Symmetrical Components based on Jim’s 40+ years of experience.
  • Spiral bound notebook with printed slides.
  • Jim’s calculation worksheets.
  • On Demand version of this class! $295 Value
  • Interactive Q&A with Jim Phillips

Live Streaming Daily Schedule

Two – 2 Hour Sessions

One Hour Break Each Day

Eastern Time

11:00 AM – 1:00 PM
2:00 PM – 4:00 PM

Pacific Time

8:00 AM – 10:00 AM
11:00 AM – 1:00 PM

Registration Deadline

It is suggested to register several days before the class in order to receive the class material.

Bonus

Access to online version of this class is included

Questions?
Call: 800-874-8883
email: Program Director

25%

Register 4 or more

30%

Register 10 or more

Group/Corporate Rates

Available

REGISTER HERE

Tickets

The numbers below include tickets for this event already in your cart. Clicking "Get Tickets" will allow you to edit any existing attendee information as well as change ticket quantities.
Per Unit | Sym. Components | September 10 - 11, 2024
Live Streaming with interactive Q&A over 2 Days | September 10 - 11, 2024 | BONUS: FREE access will be provided for the Online version of this course.
$ 495.00
Unlimited
Per Unit | Sym. Components | January 14 - 15, 2025
Live Streaming with interactive Q&A over 2 Days | January 14 - 15, 2025 | BONUS: FREE access will be provided for the Online version of this course.
$ 495.00
Unlimited

This 16 hour class by Jim Phillips, P.E. takes you through the fundamentals of the Per Unit System and Symmetrical Components which are at the heart of power system analysis.

The main purpose of Per Unit is to make the effect of transformer turns ratio mathematically disappear.  This greatly simplifies performing electric power system analysis calculations.

Many balanced three phase electrical power system problems can be solved on a per phase basis.  This means the calculations are performed for phase that represents the results on the other two phases.

However, if the system is not balanced such as the case with phase-to-phase and phase-to-ground fault calculations, Symmetrical Components are used. The concept is to solve unbalanced power system problems by resolving the problem into three sets of symmetrical balanced phasors.

Although appearing to be complex, Jim takes you through the fundamentals of each with a series of calculation examples and shows you simplifications that can be made based on his more than four decades of experience.

Per Unit and Symmetrical Components

8 Hours | 8 PDHs | 0.8 CEUs

POWER SYSTEM ANALYSIS CONCEPTS
Introduction to Power System Analysis
Resistance, Inductance and Capacitance
RLC Circuits, Series and Parallel Circuits
Delta/Wye Conversions, Complex Impedances

PER PHASE ANALYSIS

Thevenin Equivalent Impedance
Effect of Transformer Turns Ratio on Impedance
Reflecting Impedance Through Turns Ratio

PER UNIT ANALYSIS
Introduction to the Per Unit System
Why is Per Unit Necessary
Defining Base Quantities
Per Unit Voltage, Current and Impedance
Selecting the Appropriate MVA and kV Base
Calculating the Base Current and Impedance

PER UNIT CALCULATIONS
Per Unit Calculation Worksheets
Per Unit Calculation Examples and Problems
Changing Bases

PER UNIT IMPEDANCE DIAGRAMS
Developing the Per Unit Impedance Diagram
Converting Impedance from Ohms to Per Unit
Labeling the Impedance Diagram
Load Calculations using the Impedance Diagram
Per Unit Motor Starting Voltage Drop Calculation
Per Unit Short Circuit Calculations
Transformer Impedance Conversion JIM PU and Z

SYMETRICAL COMPONENTS
Unbalanced System Calculations
Balanced Vector Solutions
Positive Sequence Impedance Z1
Negative Sequence Impedance Z2
Zero Sequence Impedance Z0

SYMMETRICAL COMPONENTS AND FAULT CURRENT
Three Phase Calculations Using Z1
Line-to-Line Calculations Using  Z1 and Z0
Phase to Ground Calculations Using Z1, Z2, Z0
Sequence Diagrams
Zero Sequence Impedance and Transformer Connections


CALCULATION PROBLEMS
Creating Zero Sequence Diagrams
Calculation of Z1, Z2 and Z0 for Transmission Line Fault
Calculation of 3 Phase, Ph-Ph and Ph-Ground Faults

Questions?

For questions, registration information or to discuss holding this class at your location as an on-site training program
