Protective Device Coordination Analysis - Part 2 - 0.2 CEU/2 PDH

Course Summary – This is Part 2 of a 3 part video series on Protective Device Coordination Analysis. In Part 2, Jim Phillips, P.E. shows how to coordinate current limiting fuses, solid state circuit breakers and ground fault protection.

Learn how to select circuit breaker settings to coordinate with fuses. See what the solid state breaker L,S,I,G settings are about and how to coordinate ground fault protection.

The footage was recorded at the One Week Power Distribution Class held several times a year by T2G Technical Training Group.

Course Outline

• Current Limiting Fuse Curves
• Let Thru Current
• Fuse Selectivity Tables
• Coordinating Fuses and Breakers
• Electronic Trip Breakers
• Frame, Sensor, Plug
• L,S,I,G Functions
• Coordination with L,S, Only
• I2T Functions for Coordination
• Ground Fault Protection
• Ground Fault Requirements
• Pickup and Time Delay
• Coordinating Ground Fault
• Residually Connected Scheme

Sample Videos – Test drive before you buy. Below are three free sample videos for your review. The sample video files are large files (2-3 MB) for better quality and in Windows Media (wmf) format.

• Coordination of Breakers
• Transformer Impedance
• 3rd Harmonics and Neutrals

Continuing Education Credit – The continuing education credit for this course is 2 PDHs / 0.2 CEUs. To receive Continuing Education Credit, you simply watch the video, solve a few problems and take the test. Continuing Education Credit is credited to the person that purchased the program and must be completed within 90 days of shipment of the course material. A passing score of 70 percent is required for credit.

Workbook – The course workbook is included with this package and contains many of the illustrations used in the video as well as copies of the time current curves used in the problem solving exercises.

On – Site Training – Hold the live version of this 1 day course at your location as an on-site training program. For more information click: On-Site- Training

Questions? Call us at 800.874.8883
